About CHARCOAL PELLET MACHINE 125 KGHOUR

FABON Charcoal Pellet Machine

Eco-Friendly Solution for Charcoal Powder to Energy Pellets

Product Overview

The FABON Charcoal Pellet Machine is designed to convert fine charcoal powder, coal dust, and carbon-rich residues into uniform, high-density charcoal pellets. These pellets are widely used as a clean-burning fuel for stoves, boilers, barbecues, and industrial heating. The machine uses a high-pressure pelletizing process to ensure strong, durable pellets with low ash content and high calorific value.

Applications

• BBQ charcoal pellets (household & commercial use)

• Industrial heating pellets for boilers, furnaces, and gasifiers

• Alternative fuel for replacing coal and firewood

• Carbonized biomass powder utilization (sawdust, rice husk, coconut shell charcoal)

Key Features

• High Pressure Pelletizing: Ensures dense, durable charcoal pellets.

• Flexible Raw Materials: Works with charcoal powder, carbon black, coal dust, coconut shell charcoal, rice husk charcoal, etc.

• Energy-Efficient: Optimized compression ratio reduces power consumption.

• Adjustable Die Sizes: Produces pellets of 4 mm to 12 mm diameter.

• Durable Construction: Alloy steel dies and rollers for long service life.

• Environment-Friendly: Converts waste charcoal into value-added fuel.

Technical Specifications (Typical Model)

• Capacity: 300 kg/hr to 2 TPH (customizable)

• Pellet Size: 412 mm diameter

• Motor Power: 15 HP 100 HP (depending on capacity)

• Moisture Requirement: Raw material 812%

• Pellet Density: 1.0 1.2 g/cm

• Calorific Value of Pellets: 50006500 kcal/kg (depending on raw material)

• Final Use: Packaged 550 kg bags or bulk storage

Process Flow

1. Raw Material Preparation charcoal powder screened and moisture adjusted

2. Feeding System screw/auger feeds material into pellet mill

3. Pelletizing rollers compress material through die holes

4. Cooling & Screening hot pellets cooled to room temperature, fines removed

5. Bagging & Storage pellets packed for commercial use

Advantages

• Converts waste charcoal into high-value fuel pellets

• Easy storage & transportation compared to loose powder

• High combustion efficiency with low smoke & ash

• Suitable for domestic and industrial applications

• Strong market demand (BBQ, restaurants, industrial fuel)

Maintenance & Safety

• Regular lubrication of roller & die system

• Replacement of worn-out dies/screens as per usage

• Equipped with overload protection & emergency stop

• Safe operation with protective covers & interlocks
