FABON Poultry Feed Grinder Machine

Product Overview

The Poultry Feed Grinder Machine is designed to grind raw materials like maize, wheat, soybean meal, groundnut cake, rice polish, husk, bran, and other agro by-products into uniform particle sizes. The machine ensures efficient grinding, consistent mixing, and high digestibility of feed for poultry birds. It is versatile and can be integrated into mash feed plants, pellet feed lines, or crumble feed systems.

Applications

Mash Feed Production finely ground ingredients can be directly used as mash feed for chicks, growers, and layers.
Pellet Feed Preparation ground material is passed to the pellet mill to produce uniform poultry feed pellets.
Crumble Feed pellets produced can be crushed into smaller crumble size feed for broilers and younger birds.

Key Features

High Grinding Efficiency: Heavy-duty hammer/blade design ensures uniform grinding.
Adjustable Screen Sizes: Allows control over particle size depending on mash, pellet, or crumble requirements.
Continuous Operation: Robust motor and rotor assembly designed for 247 industrial use.
Versatility: Can grind cereals, oil cakes, husks, bran, and agro-waste materials.
Durable Construction: Made from wear-resistant steel with balanced rotor to minimize vibration.
Easy Maintenance: Quick-change sieve design, accessible hammer/blade chamber.

Technical Specifications (Typical for 5001000 kg/hr Models)

Capacity: 500 kg/hr to 5 TPH (customizable)
Motor Power: 10 HP to 75 HP (depending on plant size)
Rotor Speed: 28003000 RPM
Grinding Fineness: 0.5 mm 5 mm (adjustable)
Screen Diameter: 2 mm 8 mm (as required)
Material of Construction: Mild Steel / Stainless Steel (optional)
Output Types: Mash (direct), Pellets (via pellet mill), Crumbles (via crumbler)

Advantages

Improves digestibility and nutrient absorption of poultry feed.
Ensures homogeneous feed particles for uniform growth of birds.
Reduces feed wastage by optimizing particle size.
Energy-efficient design for lower operating cost.
Flexible integration with complete feed plants (mixer, pellet mill, crumbler, cooler).
